Setting Up Your Watch Winder Safe Pro version
Setting Up Your Watch Winder Safe Pro version
Please refer below for How to Setting User and Administrator Passwords:
Please refer below for How to Set up the fingerprint for lock
Setting the Touch Screen Control Panel for watch winder
Touch the screen to select different settings.
Watch Selection: When "AL" is displayed, touching "Run" will start all watches on the winder using the last set Turns Per Day (TPD) mode.
TPD Modes (Turns Per Day): You can choose from the following rotation settings such as: 650 turns, 750 turns, 850 turns, 1000 turns, or 1950 turns per day. The winder will operate for 12 hours and then stop for 12 hours each day.
Rotation Direction: Select the rotation direction:
- Clockwise
- Counterclockwise
- Alternate Rotation (rotates clockwise and counterclockwise)
Start or Stop: Touch the screen to toggle between Start (🞂 running) and Pause (⬛stopped).
LED/UVC Light Options:
- First Touch: Activates the LED light, which will remain on.
- Second Touch: Activates the UVC light for 10 minutes for sterilization. It will turn off automatically after 10 minutes.
- Third Touch: Turns on both the LED and UVC lights.
- Fourth Touch: Turns off both lights.
UVC (Ultraviolet C
Check the video below for a demonstration.
Special Notes:
-
12 O'Clock Automatic Stop/Home Position:
- If your watch winder has this feature, when it stops or is paused, the watch holders will automatically return to approximately the 12 o'clock position before completely stopping. This ensures your watches are displayed neatly and aesthetically.
-
Door-Activated Control Switch:
-
There is a door activation switch (As the black button shown in picture 1). This controls how opening the door affects the watch winder's operation.
-
Door-Activated Control Switch ON:
- When you open the door, it will trigger the door activation function.
- The watch holders will stop rotating, following the Note 1 - 12 o'clock automatic stop function described above.
- The LCD control screen will also light up for about half a minute.
- After closing the door, the winder will automatically resume the program that was running before it was paused. Please note: Once you close the door of watch winder safe, the winder might not start rotating right away. This is because the program that was paused might have been in a pre-programmed rest period.
-
Door-Activated Control Switch OFF:
- When the Door-Activated Control Switch is off, opening the door will not affect the previously set operation.
- If you want to pause the winder, you will need to manually pause it using the controls on the screen.
-
-
Once you have made your selections, the settings will be saved automatically. When there is a power outage, once the power is restored, it will automatically resume operation according to the original settings.
How to install wall-mounted (optional):
Just use two bolts into the wall behind it. Open the drawer, and you can make alignment marks using the two holes. Then, drill holes based on the marks and install the screws to secure it.
More information for this new version pro manual, please view Watch Winder Safe Manual
